Feature Technical Parameters:
Frequency:400-47MHz
16 channel Radio
1500mAh li-ion
Weight: 170g
General Specification
| Frequency Range | UHF 400-470MHz |
| Channel Capacity | 16 |
| Operated Voltage | 3.7 V |
| Battery | 1500MAh Li-ion |
| Frequency Stability | +2.5ppm |
| Operated Temperature | -30°c to 60°c |
| Antenna Impedance | 50 |
| Dimensions (LxWxH)(with battery, without antenna) | 110x50x32 mm |
| Weight (with battery/antenna) | 198g |
| Transmitter | |
|---|---|
| RF Power Output Modulation | 3W F3E |
| Spurious Emission | ≤65dB |
| FM Noise | ≤-45dB(W) ≤-40dB(N) |
| Audio Distortion | ≤5% |
| Transmitting Current | ≤1.3A |
